ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration

ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration
ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration

Großes Bild :  ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration

Produktdetails:
Place of Origin: CHINA
Markenname: FILTERK
Zertifizierung: ISO 9001
Model Number: ZSWL
Zahlung und Versand AGB:
Minimum Order Quantity: 10pcs
Packaging Details: Plastic bag inside,carton outside. Optional: Pallet or wooden case for large quantities.(Need extra cost)
Delivery Time: 1 week
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 1000pcs/week
Kontakt

ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration

Beschreibung
Application: liquid filtration Diameter: 2.5 inches
Efficiency: 99% Flow Rate: 10 gallons per minute
Certifications: NSF/ANSI 42 Filter Material: Fiberglass
Filtering Precision: 5 μm End Cap Type: Flat
Operating Temperature: 40-140°F Condition: New
Outer Diameter: 69mm Filtering Area: 4.6m2
Length: 10 inches Filtering Accuracy: 5 μm
Package: Custom Package

ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration


ZSWL porous metal membrane adopts continuous slurry impregnation + asymmetric alloy metal separation membrane preparation method, adopts macroporous support matrix composite micron-grade metal powder sintering separation layer, has a stepped pore structure, has high efficiency, low resistance, high precision performance advantages, is the most ideal and advanced filter material in the field of high temperature flue gas treatment.

The macroporous matrix of the ZSWL-porous metal membrane provides high permeation flux, the microfiltration separation layer provides high-precision separation, and the high-strength skeleton ensures that the high-frequency backwash metal membrane can achieve long-term operation to avoid bag breakage and corrosion. Achieve high-throughput, high-precision, and long-life stable operation.


Specifications:

Parameter Details
Product Name ZSWL Porous Metal Membrane Filter Cartridge
Material Stainless Steel 316L / 304, Hastelloy, Inconel (optional)
Filtration Accuracy 0.5 – 100 μm
Porosity 30% – 50%
Operating Temperature Up to 600°C (Depending on material)
Max Operating Pressure ≤ 30 MPa
Structure Cylindrical / Pleated / Disc / Custom shapes
Outer Diameter 30 – 100 mm (customizable)
Length 100 – 1000 mm (customizable)
End Cap Type DOE, 222/Fin, 226/Flat, Threaded, Custom
Cleaning Method Backflushing, Ultrasonic, Chemical Cleaning
Application Liquid & Gas Filtration, Petrochemical, Food & Pharma, High-Temp Systems

ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration 0

ZSWL Porous Metal Membrane Filter Cartridge – Application Fields

  • Chemical and petrochemical filtration

  • Pharmaceutical and food-grade fluid purification

  • Gas and steam filtration in power and energy sectors

  • Wastewater treatment and environmental protection

  • High-temperature and high-pressure industrial filtration

  • Fuel, oil, and gas filtration in aerospace and automotive industries

  • Ultrapure liquid and gas filtration in electronics and semiconductors

Package & Delivery

ZSWL Sintered Metal Fiber Felt Membrane Filter Cartridge for Precision Filtration 1


Service Provide:

OEM service, printing or logo information is acceptable.


Größe und Tag:

gefalteter Sedimentfilter,

synthetischer Luftfilter,

Polyester-Filter
